Micro Coax LCD Display Cable Assembly Overview

This custom micro coax LCD display cable assembly is designed for high-density
board-to-board display interconnection applications requiring stable signal transmission,
compact installation space, and reliable long-term performance.

The assembly utilizes thirty ultra-fine 50Ω micro coaxial conductors combined with 0.4mm
pitch board-to-board connectors. Its low-profile structure makes it suitable for modern LCD,
OLED, industrial display, medical imaging, embedded computing, and portable electronic
systems where space constraints and signal integrity are critical.

With controlled impedance construction and precision termination technology, the cable
helps reduce signal loss, EMI interference, and transmission instability while supporting
high-speed display communication.

The lightweight cable structure also simplifies routing inside compact electronic products
and helps engineers achieve cleaner internal layouts.

Key Features of Micro Coax Display Cable Assembly

Ultra-Fine 50Ω Micro Coax Construction

Each conductor utilizes miniature coaxial cable technology to provide excellent impedance
consistency and signal stability.

High Density 0.4mm Pitch Interface

Supports compact electronic designs with limited PCB space requirements.

Excellent Signal Integrity

Suitable for high-speed differential and display signal transmission applications.

Low Profile Design

Supports display modules with stacking heights as low as 0.98mm.

Custom Manufacturing Available

Cable length, pin assignment, shielding structure, and connector configuration can all be
customized.

100% Electrical Tested

Every assembly undergoes continuity, open, short, and intermittent testing before shipment.

Micro Coax Display Cable Assembly Specifications

Applications of Micro Coax Display Cable Assembly

LCD Display Modules

Used for high-resolution LCD panel interconnection in industrial equipment.

OLED Display Systems

Supports compact OLED display integration with minimal space requirements.

Medical Imaging Equipment

Ideal for ultrasound systems, diagnostic displays, and portable medical devices.

Industrial Control Panels

Provides stable display signal transmission in automation systems.

Embedded Computing Devices

Suitable for SBC, IPC, ARM platforms, and custom embedded displays.

Portable Electronic Equipment

Commonly used in handheld terminals, testing equipment, and mobile devices.

Custom Micro Coax Cable Assembly Manufacturing
Options

Sino-conn provides complete customization services for display cable assemblies.

Available customization options include:

• Cable length customization
• AWG44 / AWG46 / AWG48 micro coax options
• Connector pitch customization
• Pin count customization
• Shielding enhancement
• EMI optimization
• Adhesive reinforcement
• Protective wrapping solutions
• Label printing
• Assembly testing reports

OEM and ODM projects are welcome.
