105411-1104 4 Circuit Custom Power Cable Assembly
The 105411-1104 4 Circuit Power Cable Assembly is a custom electrical cable assembly designed
with 16AWG UL1180 PTFE insulated wire and a compact 4-circuit panel-mount connector configuration.
The cable uses UL1180 PTFE wire rated at 300V and 200°C, making it suitable for high-temperature
electrical connection applications. The specified cable configuration uses red and blue wires with
a 268 ± 2 mm cutting length.
The assembly is designed for reliable electrical connection and is subject to 100% open, short
and intermittent testing. The product is also specified as RoHS3.0 compliant.
The 105411-1104 cable assembly uses a 4-circuit configuration with UL1180 PTFE insulated
wire and terminal connections.
The main cable structure includes:
The specified terminal is designed for 14/16AWG wire, while the cable specification uses
16AWG conductors.
| Specification | Details |
|---|---|
| Product Type | Custom Power Cable Assembly |
| Model / Connector P/N | 105411-1104 |
| Circuit Count | 4 Circuits |
| Wire Type | UL1180 PTFE |
| Wire Gauge | 16AWG |
| Voltage Rating | 300V |
| Temperature Rating | 200°C |
| Wire Colors | Red / Blue |
| Cutting Length | 268 ± 2 mm |
| Connector Pitch | 5.7 mm |
| Compliance | RoHS3.0 Compliant |
The 105411-1104 connector configuration is a 4-circuit panel-mount plug housing with a 5.7 mm
pitch. The assembly also uses a 4-circuit TPA component for terminal retention.
The specified connector system is designed for secure terminal positioning and compact
panel-mounted electrical connections.
The 105411-1104 cable assembly uses UL1180 PTFE insulated wire with a rated temperature
range of -60°C to +260°C for the wire material specification, while the applicable UL rating is
specified as 200°C and 300V.
The wire specification also includes:
The wire specification lists a conductor construction of 19/0.30 and a nominal outer diameter
of 2.18 ± 0.10 mm.
The 105411-1104 power cable assembly is specified for 100% electrical testing during production.
The testing requirements include:
These requirements are specified as part of the cable assembly quality requirements.
The 105411-1104 4 Circuit Power Cable Assembly is suitable for electrical connection applications
that require multiple power circuits, high-temperature insulation and a compact connector configuration.
Potential application areas include:
The combination of 16AWG PTFE wire, 300V rating and high-temperature insulation makes this
configuration suitable for applications where thermal resistance and reliable electrical connection
are important.
The 105411-1104 cable assembly can be manufactured as a customized cable solution according
to required wire length, wire color, terminal configuration and assembly requirements.
The standard configuration specifies a 268 ± 2 mm cutting length, with red and blue wire identification
for the four-circuit assembly.
