IDC 4-Pin Shielded Cable Assembly
IDC 4-Pin Shielded Cable Assembly
– Custom OEM Interconnect
IDC 4-Pin Shielded Cable Assembly:
This IDC 4-Pin Shielded Cable Assembly is a custom OEM interconnect designed for
industrial and control applications requiring stable low-voltage signal transmission and
mechanical reliability.
The assembly features 4-position IDC female and male connectors (models 3-647002-4
and 3-640442-4) terminated on a LIYCY 4-core shielded cable with aluminum Mylar foil
and braided shielding.
Heat-shrink tubing and controlled strain-relief zones ensure durability in fixed or
semi-dynamic installations.
Cable length, pin assignment, wire colors, and labeling are fully customizable according
to customer drawings and system requirements.
IDC 4-Pin Shielded Cable Assembly – Key Features:
4-Position IDC Connector Interface
Compact IDC termination for reliable insulation displacement contact.
Female to Male Configuration
Designed for direct board-to-board or module-to-module interconnection.
Shielded Multi-Core Cable Structure
Aluminum Mylar foil + braided shield reduce EMI and external noise.
26 AWG Tinned Copper Conductors
Stable electrical performance with consistent crimp quality.
Heat-Shrink Reinforced Ends
Improved strain relief and long-term mechanical protection.
Custom OEM Manufacturing
Built strictly to customer drawings, pinouts, and test requirements.
IDC 4-Pin Shielded Cable Assembly – Typical Applications:
Industrial control systems
Sensor and actuator wiring
Embedded electronic modules
Automation and instrumentation equipment
Custom low-voltage signal harnesses
IDC 4-Pin Shielded Cable Assembly – Technical Specifications:
| Parameter | Description |
|---|---|
| Product Type | IDC Shielded Cable Assembly |
| Connector A | 4-Pin IDC Female, Model 3-647002-4 |
| Connector B | 4-Pin IDC Male, Model 3-640442-4 |
| Contact Material | Tinned copper |
| Wire Type | LIYCY 4C × 0.14 mm² |
| Conductor Gauge | 26 AWG |
| Shielding | Aluminum Mylar + braided shield |
| Outer Diameter | Approx. 4.5 mm |
| Cable Length | 1500 mm ±20 mm (customizable) |
| Wire Colors | White / Brown / Green / Yellow |
| Insulation Resistance | ≥20 MΩ @ DC 200 V |
| Hi-Pot Test | AC 200 V / 0.1 s |
| Contact Resistance | ≤3 Ω |
| Electrical Test | 100% open / short test |
| Compliance | RoHS compliant |
| Manufacturing Mode | Custom OEM production |
IDC 4-Pin Shielded Cable Assembly – Customization Options:
Cable length and jacket material
Connector gender and orientation
Pin assignment and wire color sequence
Shielding structure (foil / braid / combined)
Heat-shrink length and labeling content
Packaging and serialization
Engineering support is available from sample build to mass production.
