20380-R20T-06 20-Pin Cable Assembly
20380-R20T-06 20-Pin Micro-Coax Internal Connector
Cable Assembly
20380-R20T-06 Cable Assembly Overview:
The 20380-R20T-06 20-Pin Micro-Coax Internal Connector Cable Assembly is designed for
high-density internal interconnection in compact electronic devices.
This cable assembly adopts a micro-coaxial wire structure to support stable signal
transmission in applications where limited space, flexibility, and controlled impedance
are required.
It is commonly used for internal board-to-board or module-to-module connections where
precise pin alignment and mechanical reliability are critical.
20380-R20T-06 Cable Assembly Applications:
All application descriptions are based on structural usage and do not assume any specific
communication protocol.
20380-R20T-06 Cable Assembly Specifications:
| Item | Specification |
|---|---|
| Connector Model | 20380-R20T-06 |
| Connector Type | Micro-Coax Internal Connector |
| Pin Count | 20 |
| Cable Type | Micro-Coaxial Cable |
| Wire Gauge | 42 AWG |
| Characteristic Impedance | 45 Ohm |
| Cable Length | Custom (Reference: ~1080 mm) |
| Outer Diameter | Max Ø 2.5 mm |
| Cable Assembly Type | Board-to-Board |
| Compliance | RoHS / REACH |
Key Advantages of 20380-R20T-06 Cable Assembly:
High-density 20-pin layout suitable for compact assemblies
Micro-coax cable structure supports stable signal performance
Flexible construction suitable for constrained or dynamic routing paths
Compact outer diameter enables efficient internal cable management
Suitable for customized internal interconnection solutions
20380-R20T-06 Cable Assembly Customization:
The 20380-R20T-06 Cable Assembly can be customized according to drawings or samples.
Customization options include cable length, pin assignment, wire arrangement, shielding
structure, insulation length, and connector orientation to meet specific mechanical and
electrical requirements.
20380-R20T-06 Cable Assembly Manufacturing & QC:
Each 20380-R20T-06 Cable Assembly undergoes standardized manufacturing and inspection
processes, including continuity testing and visual inspection, to ensure consistent quality and
reliable performance for both prototype and mass production.
Sino-Media is a specialized cable assembly manufacturer. We utilize cutting-edge
automation equipment, premium raw materials, a robust quality assurance system,
and a skilled technical team to deliver high-quality, custom cable and harness
components in small quantities. Our engineering, production, and quality control
teams ensure the excellence of these unique components. Our mission is to enhance
product quality continuously, meet customer needs, and maintain expertise in the
materials we use and recommend. Our dedication to customer satisfaction drives
the company’s ongoing growth.
