50mm 6-Wire Wire Harness with HX25402-6Y Connectors Custom UL1007 24AWG

6-Wire Cable Assembly with HX25402-6Y Connectors

This 50mm 6-wire cable assembly is designed with HX25402-6Y connectors on both ends

and UL1007 24AWG wire. The cable uses a defined pin-to-pin wire connection and color

arrangement according to the engineering specification.

It is suitable for custom cable assembly requirements where compact length, six-wire

configuration and consistent connector termination are required.

6-Wire Cable Assembly Specifications

6-Wire Cable Assembly Wire Connection

The cable assembly follows a defined pin-to-pin connection:

• Pin 6 → Black → Pin 6
• Pin 5 → White → Pin 5
• Pin 4 → White → Pin 4
• Pin 3 → White → Pin 3
• Pin 2 → NC → Pin 2
• Pin 1 → Red → Pin 1

This fixed wire mapping helps maintain consistent electrical connections during cable assembly

production.

6-Wire Cable Assembly with HX25402-6Y Connectors

The cable is terminated with HX25402-6Y connectors at both ends. HX25402-PT crimp terminals

are specified for the wire termination.

The connectorized construction provides a ready-to-use cable assembly rather than loose individual

wires, making it suitable for applications requiring a defined six-wire connection interface.

Custom 6-Wire Cable Assembly

Custom cable assembly production can be developed according to customer requirements, including

cable length, wire configuration, connector selection and pin assignment.

For projects requiring a different cable length, connector configuration or wire specification, customers

can provide their drawing or technical requirements for engineering review.

6-Wire Cable Assembly Quality Testing

The engineering specification requires electrical testing of the finished cable assembly, including:

• Open-circuit test
• Short-circuit test
• Missing-wire test
• Intermittency test
