0.4mm Pitch Coaxial Cable Connector ROHS
20380 -R30T-06 cable:
| Mating type |
Vertical
|
| Contact pitch |
0.400 mm
|
| Max Height |
1.85 mm
|
| Depth |
3.000
|
| Width Formula |
5.80+(0.4*?p) mm
|
| Pin count |
10 14 20 30 32 35 40 50
|
| Micro-Coaxial Cable (AWG) |
#38 #40 #42 #44 #46
|
| Current rating |
0.24A AC/DC [AWG #42] per contact/up to 50 contacts
0.25A AC/DC [AWG #40] per contact/up to 50 contacts 0.30A AC/DC [AWG #40] per contact/up to 32 contacts 0.35A AC/DC [AWG #36] Pper contact/up to 50 contacts 0.40A AC/DC [AWG #36] per contact/up to 37 contacts 0.35A AC/DC [AWG #34] per contact/up to 50 contacts 1.00A AC/DC [AWG #34] per contact/up to 2 contacts |
Widely used in computers, medical equipment, security equipment, security equipment, laptops,
High-definition camera, miniature coaxial cable assembly, smart home appliances. The reason is used in automobiles,
electronics,Industrial, medical equipment, UAV miniature coaxial cable assemblies, miniature coaxial cable assemblies.
Wire or cable used: micro coaxial cable, thin coaxial cable, SGC cable, wire, micro coaxial cable,MCX cables,
shielded cables, wires, flexible welding cables, micro coaxial cables and power cables
20345-30T-32R cable:
| Mating Direction | Horizontal |
| Contact pitch | 0.40 mm |
| Height | 1.15 Max (1.00 Nom.) , |
| Pin count | 10 15 20 25 30 35 40 |
| Micro-Coaxial Cable (AWG) | #40 #42 #44 #46 |
| Discrete Cable (AWG) | #36 #38 #39 #40 #42 #44 #46 |
Micro coaxial Cable assemblies, eDP Cable assembly, LVDS Cable Assembly, micro coaxial cable,
Fine pitch Wire Harness manufacturers
Cable connector brand such as , KEL, Hirose, ACES, JAE,JST, Molex and others
eDP/LVDS interface 20453-330T, 20455-230E, 20682, 20679, 20788, 20790, 20856, 20633, 20525
,20728, 20729 etc
