|Product Name:||RF Coaxial Connector||Material:||Brass|
|Keywords:||Edge Mount RF Connector||Function:||Dustproof|
|Usage:||Military/aerospace||Item:||RF Straight Connector|
|Frequency Range:||DC - 67 GHz||Apply To:||Edge Mount PCB|
Copper RF Straight Connector,
DC 67GHz RF Straight connector,
Dustproof RF Connector
1.85-KHD RF connector copper connector antenna pcb board
straight connector for Military/Aerospace
|VSWR:||1.30 Max @ 67 GHz|
|Frequency Range:||DC - 67 GHz|
|Durability:||≥ 500 Cycles|
|Apply to:||Mixed Tech PCB|
● Impedance: 50 Ω ● Insulation Resistance: 5000 MΩ Min
● Frequency Range: DC - 67 GHz ● Dielectric Withstanding Voltage: 500 Vrms Min (Sea Level)
● VSWR: 1.30 Max @ 67 GHz ● Contact Resistance: ≤ 3 mΩ (Center Contact)
● Insertion Loss: ≤ 0.49 dB @ 67 GHz ≤ 2 mΩ (Outer Contact)
● Mateable with 2.4 mm, V Series ● Center Contact Retention Force: 6 lbs Min
● Durability: ≥ 500 Cycles ● Coupling Torque: 7 - 8 lb-in Recommended
● Temperature Range: -55 ℃ to +85 ℃
Material & Finish
● Body: Brass, 10 μ" Gold ● Dielectric: Engineering Plastic, Natural
● Center Contact: Beryllium Copper, 30 μ" Gold
● High Volume Production Test Stations ● PCB Connections
● Research & Development Labs
● RoHS Compliant ● Good Stability Design
● High Performance
Typical Performance Data (@ 25℃)
DUT: 2 PCS 1.85 mm Female, Straight Connectors (Back to Back)
We offer our customers a small number of highly specialized cable and harness assemblies,
and our engineering department, production and quality control ensure the highest quality
of these unique components
Please feel free to contact us for custom OEM/ODM.
