|Product Name:||Hirose DF36-30P-0.4SD LCD Micro Coax Lvds Edp Cable Assembly||Contact Pitch:||0.4 Mm Pitch|
|Micro-Coaxial Wire (AWG):||#42 #46||Express:||DHL FEDEX UPS TNT|
LVDS EDP Micro Coax Cable Assembly,
DF36-30P-0.4SD Micro Coax Cable Assembly,
46AWG LVDS Cable Assembly
LVDS EDP Micro Coax Cable Assembly HIROSE DF36-30P-0.4SD Length customize
DF36 30pin data sheet:
|Number of Positions||15, 20, 25, 30, 40, 45, 50|
|Recommended Min. Wire Size (AWG)||42AWG 46AWG|
|Operating Temperature Max.||-35 ℃ 85 ℃|
0.25A (42 AWG)
0.25A (44 AWG)
0.1A (46 AWG)
0.4 mm pin pitch, 1.5 mm assembly height, board-to-fine wire coaxial connector
1. Small assembly height and board footprint
2. Reinforced shielding and ground connection
3. Reliable latch
4. Reliable electrical performance and mechanical Connection
5. De-tinning resistance
6. High-durability mating structure
7. Lead-free, halogen-free
LVDS cable,LCD cable,eDP cable,IPEX LVDS cable,LCD Ribbon cable
Hirose DF36 Common used connector part number:
DF36C-15P-0.4SD DF36-20P-0.4SD DF36-25P-0.4SD DF36-30P-0.4SD
DF36-40P-0.4SD DF36-45P-0.4SD DF36-50P-0.4SD
Hirose micro coaxial cable:
The camera with 2 million 1080P MIPI signals, impedance ask for 100±10Ω, but Teflon discrete wire can
only with 100±15Ω, and the pitch of the discrete wire is unstable during the production process, there is
with a risk of flickering. Micro coaxial cable can meet the impedance requirements very well; in addition,
cameras that can rotate at a large angle ask for higher requirements for the life of the internal connectors,
so currently most of them use ffc cable assemblies, HRS DF36 micro coaxial cable, KEL USL20-30S, etc.
